When working, the plow blade moves in a circular motion, and the material is divided into two directions by the plow blade surface to form a bidirectional material flow. It intersects with the materials diverted from both sides of the plow blade to form convection. When the material flows through the high-speed flying blade, it is sheared and thrown by the high-speed flying blade blades, thus achieving uniform mixing in a short period of time. The mixing accuracy of this machine is high, and there is no segregation during mixing, especially for materials that are prone to agglomeration, it can play a role in depolymerization and dispersion.
Cylinder volume(KW) | Load factor(L) | Flying knife motor power(MM) | Working pressure of discharge cylinder(MPa) | Working voltage (V) |
2000 | 2.2~0.5 | 2.2 | 0.6 | AC380 |
Flying knife speed(rpm) | Plowing speed(rpm) | Plowing blade motor power(KW) | Working pressure of shaft seal(MPa) | External dimensions(MM) |
1440 | 63 | 18.5 | <0.1 | 3023*1515*1568 |
Non standard customization is possible |
